Technical Data Sheet
Item 1314 – MODULAR ISLAND A 3 with 105-liter Capacity
The Ecological Island consists of 3 modules with a metal base, thickness 5 mm, and dimensions 45 x 49 cm, featuring a lid with 3 openings.
Each module is made up of a 105-liter frustum-shaped container, 80 cm tall, with a base diameter of 37 cm and a top diameter of 44 cm, constructed from polyethylene using rotational molding technology.
This material provides high resistance to impacts, aging, and fading.
The lid is made of thermoformed and painted ABS, featuring 3 openings: one front opening and two side openings, each measuring 23.5 x 8.5 cm. The lid is secured to the container body using a triangular insert key.
The metal bases undergo cataphoresis treatment followed by epoxy powder coating (for outdoor use, they can also be hot-dip galvanized upon request). The modules are connected by a metal joint measuring 21 x 6 cm with a thickness of 5 mm.
At both ends of the island, there are metal end caps with a thickness of 5 mm, which add weight and enhance the aesthetic appeal. The structure does not require anchoring to the ground.
Minimum Characteristics and Dimensions:
